| Specification | M12 |
| Mounting | Flushed |
| Sensing distance | 2mm |
| Set distance | 0.5~3mm |
| Hysteresis error | 3~15% of sensing distance |
| Repeat accuracy | ＜3% of sensing distance |
| Output mode | NPN/PNP |
| Response frequency | 50Hz |
| Temperature effect | -25℃~70℃, sensing distance within ±20% at +23℃
|
| Power supply | DC 12-24V pulse(p-p)＜10%(DC 10-30V) |
| Current consumption | ＜15mA |
| Voltage effect | ＜3% |
| Residual voltage | ＜2.5V (load current 200mA＆cable 2m） |
| Load current | <200mA |
| Circuit protection | Reverse polarity connection protection, short circuit protection, electrical surge absorption |
| Indicator light | Output: organge LED; Power: Green LED |
| Leakage current | ＜100uA |
| Connection | Cable 2m |
| Ambient temperature | Work＆store: -25℃~70℃ |
| Ambient humidity | Work＆store: 35% ~ 95%RH |
| Anti-vibration | 10~55Hz, 1.5mm double amplitude for 2H each in,X,Yand Z directions |
| Withstanding voltage | 750V AC, 50/60Hz for 1min between current-carrying parts and case |
| Insulation resistance | >20MΩ min at 500V DC between current-carrying parts and case |
| Protection degree | IEC IP67 |
| Housing | PBT |
